ZOOM Mixer / Multitrack Recorder / Interface / Controller LIVETRAK L‑12

Công ty TNHH TMĐT Chu Vũ chuyên cung cấp Sản Phẩm  Zoom Chính hãng giá tốt. Quý khách có nhu cầu vui lòng liên hệ: 0939 24 0939 để được tư vấn sản phẩm và giá tốt nhất tại thời điểm mua hàng

THÔNG TIN SẢN PHẨM

Twelve-channel digital mixing system.

The Zoom LiveTrak L-12 is a portable mixing system with great sound and features. Not only can you mix up to 12 individual channels, but you can also create custom headphone mixes for up to five band members and craft a polished live mix complete with studio-quality effects.

You can complete your entire project on the L-12 or transfer all 12 discrete tracks to your DAW for editing and mixing. The LiveTrak L-12 also functions as a 14-in/4-out USB audio interface for your Mac, PC, or iOS device.

Channels 3–8 have a -26dB pad for capturing loud sources, and a clear 12-segment LED metering helps you keep an eye on your levels. You can save up to 9 scenes and recall your custom settings automatically. You can even program the mixer to record automatically when the master fader detects a certain dB level. Capture data up to 2 seconds before recording starts. It includes a built-in slate mic for recording comments or talk back and an onboard metronome for keeping the band in sync.

• 12-channel digital mixer (8 mono/2 stereo)
• 14-in/4-out USB audio interface for your Mac, PC, or iOS device (Apple Lightning-to-USB Camera Adapter is required for iOS)
• 12-track 24-bit/96kHz recording directly to an SD card
• Record up to 48kHz to a computer and an SD card simultaneously
• Create customizable, savable headphone mixes for up to 5 band members
• Complete your entire project on the mixer, or transfer all 12 discrete tracks to your DAW for editing and mixing
• 8 combo jacks accommodate both XLR and 1/4" connectors
• 8 great-sounding mic preamps with phantom power and +60dB of gain
• Channels 1–2 offer hi-Z inputs for your electric guitar or bass
• Channels 9/10 and 11/12 have TRS and RCA connectivity for keyboards and other audio devices
• Each channel features a 3-band mid-parametric EQ and 16 built-in effects
• Channels 1–8 include a dedicated compressor for controlling dynamics
• Channels 3–8 have a -26dB pad for capturing loud sources
• Clear 12-segment LED metering for keeping an eye on your levels
• Save up to 9 scenes and recall your custom settings automatically
• Record automatically when the master fader detects a certain dB level

  THÔNG TIN SẢN PHẨM

  Twelve-channel digital mixing system.

  The Zoom LiveTrak L-12 is a portable mixing system with great sound and features. Not only can you mix up to 12 individual channels, but you can also create custom headphone mixes for up to five band members and craft a polished live mix complete with studio-quality effects.

  You can complete your entire project on the L-12 or transfer all 12 discrete tracks to your DAW for editing and mixing. The LiveTrak L-12 also functions as a 14-in/4-out USB audio interface for your Mac, PC, or iOS device.

  Channels 3–8 have a -26dB pad for capturing loud sources, and a clear 12-segment LED metering helps you keep an eye on your levels. You can save up to 9 scenes and recall your custom settings automatically. You can even program the mixer to record automatically when the master fader detects a certain dB level. Capture data up to 2 seconds before recording starts. It includes a built-in slate mic for recording comments or talk back and an onboard metronome for keeping the band in sync.

• 12-channel digital mixer (8 mono/2 stereo)
• 14-in/4-out USB audio interface for your Mac, PC, or iOS device (Apple Lightning-to-USB Camera Adapter is required for iOS)
• 12-track 24-bit/96kHz recording directly to an SD card
• Record up to 48kHz to a computer and an SD card simultaneously
• Create customizable, savable headphone mixes for up to 5 band members
• Complete your entire project on the mixer, or transfer all 12 discrete tracks to your DAW for editing and mixing
• 8 combo jacks accommodate both XLR and 1/4" connectors
• 8 great-sounding mic preamps with phantom power and +60dB of gain
• Channels 1–2 offer hi-Z inputs for your electric guitar or bass
• Channels 9/10 and 11/12 have TRS and RCA connectivity for keyboards and other audio devices
• Each channel features a 3-band mid-parametric EQ and 16 built-in effects
• Channels 1–8 include a dedicated compressor for controlling dynamics
• Channels 3–8 have a -26dB pad for capturing loud sources
• Clear 12-segment LED metering for keeping an eye on your levels
• Save up to 9 scenes and recall your custom settings automatically
• Record automatically when the master fader detects a certain dB level

  THÔNG SỐ KỸ THUẬT

  Format

  Analog/digital:   Digital

  Busses/groups: 4

  Aux sends:          Monitor panel

  Powered:            No

  Inputs

  Total inputs:       12

  Mic preamps:    8

  XLR/TRS combo jacks:    8

  XLR only jacks:   0

  1/4" only jacks: 4

  S/PDIF in: No

  ADAT/optical in:               No

  RCA in:  2 x Stereo

  AES/EBU: No

  Outputs

  XLR out:               2 (master)

  1/4 in. out:          2 (monitor)

  S/PDIF out: No

  ADAT/optical out:            No

  RCA out:              No

  AES / EBU:           No

  Other Connectivity

  Connections:     USB

  MIDI I/O:             No

  Headphone output(s):  1

  USB        1 Type B, 1 Type A

  Onboard effects

  Compression:    Yes

  Reverb:                Yes

  Delay:   Yes

  Chorus/flange:  Yes

  Equalization

  Type:     Rotary

  EQ bands:            3-Band, low cut

  Master graphic: No

  Other

  Dimensions (W x D x H): 445 x 282 x 70.5 mm

  Weight: 2,53 kg
