Blackmagic Design 2110 IP Mini BiDirect 12G SFP Converter

Công ty TNHH TMĐT Chu Vũ chuyên cung cấp Blackmagic Design Chính hãng giá tốt. Quý khách có nhu cầu vui lòng liên hệ: 0939 24 0939 để được tư vấn sản phẩm và giá tốt nhất tại thời điểm mua hàng.

CONVNVIPF/IP/12GSFP - Overview

The Blackmagic Design 2110 IP Mini BiDirect 12G SFP lets you convert broadcast cameras with SDI connections to SMPTE-2110 IP video systems over long distances using optical fiber. Its 12G-SDI connection supports SD, HD and Ultra HD standards up to 2160p60 and even handles the SDI program return. Blackmagic 2110 IP Mini BiDirect 12G SFP also has a 5 pin XLR talkback headset connection with talkback volume control and a press to talk button. The SFP socket will accept 10G Ethernet, 3G-SDI, 6G-SDI or 12G-SDI optical modules. It also includes a 12 DC power supply.

• Features:

  • All converters conform to the SMPTE-2110 IP video standard.
  • Choose between Mini Converter or rack mount models.
  • Uses readily available 10G Ethernet for low cost installation.
  • Re-syncs SDI inputs to a common PTP clock.
  • Includes NMOS Protocol for building a virtual router.
  • Low latency, open standard Blackmagic IP10 codec.
  • Supports all SD, HD and Ultra HD formats up to 2160p60.



• Specifications:

  • Connections
  • SDI Video Inputs: 1
  • SDI Video Outputs: 1
  • SDI Rates: 270Mb, 1.5G, 3G, 6G, 12G
  • SMPTE ST-2110 IP Video Inputs/Outputs: 1x 10G Ethernet
  • Analog Audio Inputs: 1x 5 pin XLR Talkback
  • Analog Audio Outputs: 1x 5 pin XLR Talkback
  • SDI Audio Inputs: 16 Ch embedded audio on SDI input
  • SDI Audio Outputs: 16 Ch embedded audio on SDI loop output
  • SMPTE ST 2110 IP Audio Inputs: 16 Ch embedded audio on ST-2110 IP video via 10G Ethernet
  • SMPTE ST 2110 IP Audio Outputs: 16 Ch embedded audio on ST-2110 IP video via 10G Ethernet
  • Multi Rate Support: Auto detection of SD, HD, 2K, Ultra HD and 4K
  • Reclocking: Yes
  • Ethernet: 1x 10Gb/s SFP optical fibre sockets supporting up to 10/100/1000/10G BASE-T for SMPTE-2110 IP video in and out, configuration and firmware updates
  • Computer Interface: 1x USB-C 3.0 for configuration and firmware updates

    SDI Video Standards
  • SD Video Standards: 525i59.94 NTSC, 625i50 PAL
  • HD Video Standards: 720p50, 720p59.94, 720p60, 1080i50, 1080i59.94, 1080i60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p47.95, 1080p48, 1080p50, 1080p59.94, 1080p60, 1080PsF25, 1080PsF29.97, 1080PsF30
  • Ultra HD Video Standards: 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p47.95, 2160p48, 2160p50, 2160p59.94, 2160p60
  • 4K Video Standards: 4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI, 4Kp29.97 DCI, 4Kp30 DCI, 4Kp47.95 DCI, 4Kp48 DCI, 4Kp50 DCI, 4Kp59.94 DCI and 4Kp60 DCI
  • SDI Video Rates: SDI video connections are switchable between standard definition, 720p, 1080i, 1080p, 2K DCI, Ultra HD and 4K DCI
  • SDI Color Precision: 4:2:2
  • SDI Color Space: YUV
  • SDI Auto Switching: Automatically detects SD, HD, 2K DCI, Ultra HD and 4K DCI. Level A and B is automatically detected on 3G-SDI input and user selectable on 3G-SDI output

    IP Video Compliance
  • SMPTE 2110-20 (Uncompressed Video): IGMP v2
  • SMPTE 2110-21 (Traffic Shaping) Sender: Narrow, Receiver: Narrow, Wide Synchronous, Asynchronous
  • SMPTE 2110-30 (PCM): Audio Conformance level: Level C
  • SMPTE 2110-40 (Ancillary Data): Full access to entire SMPTE ancillary data stream. Includes RP 188/SMPTE 12M-2, closed captioning and HDR static metadata
  • Codec: Blackmagic IP10 codec used when converting 12G-SDI rates to 10G 2110 IP video
  • Precision Time Protocol: IEEE 1588-2008 (PTP v2), ST 2059-1, ST 2059-2
  • NMOS IS-04 Discovery and Registration: v1.3.2, Peer-to-peer via mDNS/DNS-SD
  • NMOS IS-05 Connection Management: v1.1.2
  • NMOS BCP-002-01: Natural Grouping
  • NMOS BCP-004-01: Receiver capabilities

    Talkback and Tally
  • Talkback: 5-pin XLR talkback headset connection for talkback on channels 15/16 in the SDI and 2110 IP video.
  • Live Tally Indicator: Tally LED indicator light

    Operating Systems
  • Mac 13.0 Ventura, Mac 14.0 Sonoma or later, Windows 10 and 11

    Environmental Specifications
  • Operating Temperature: 41°F to 104°F (5°C to 40°C)
  • Storage Temperature: -4°f to 113°F (-20°C to 45°C)
  • Relative Humidity: 0% to 90% non-condensing



• Item Includes:

  • 1x Blackmagic Design 2110 IP Mini BiDirect 12G SFP
  • 1x DC Power Supply
